Nema 8 mini hybrid stepper motor 2 phase 0.6A 3.9V motor 15mN.m high torque for Medical Beauty Equipment

20*30mm Casun 0.6A Nema 8 Stepper Motor

20*20*30mm NEMA 8 Hybrid Mini Stepper Motor 0.6A 15mN.m with CE

Use with a microstepping driver to reduce vibration and achieve higher step resolution.

Choose a baseline version or request your own customized configuration.

Features:

• The standard chassis size is 20×20mm (NEMA 8), which is lightweight and suitable for precision equipment with limited space.

• Suitable for portable or small automation devices.

• Low inertia rotor, fast start and stop, and sensitive response.

• Single-axis or dual-axis output, easy to install couplings or encoders

• Available in 4-wire (bipolar) or 6-wire (unipolar) versions to adapt to different drives.

• RoHS/CE compliance: meets environmental and safety standards.

• Our engineers will be in touch within 48 hours to provide the best solution

Motor Specifications

Operating Specifications

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Submodels

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

FAQ

1. who are we?

We are based in Guangdong, China, start from 2011,sell to Domestic Market(63.00%),Western Europe(12.00%),North America(9.00%),Eastern Asia(8.00%),Northern Europe(2.00%),Eastern Europe(00.00%),Southeast Asia(00.00%),Oceania(00.00%),Mid East(00.00%),Southern Europe(00.00%),South Asia(00.00%). There are total about 51-100 people in our office.

2. how can we guarantee quality?

Always a pre-production sample before mass production;

Always final Inspection before shipment;

3.what can you buy from us?

Stepper Motor,BLDC Motor

4. why should you buy from us not from other suppliers?

We are specialized in producing and selling stepper motors for more than 11 years.

5. what services can we provide?

Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery；

Accepted Payment Currency:USD,CNY;

Accepted Payment Type: T/T,L/C,D/P D/A,,PayPal;

Language Spoken:English,Chinese,Japanese

Options:

Encoder	Brake	Gearbox	Shaft

Please click the "Get a quote" button below to tell us your requirements.
